- AOYUE Int 936A
DESCRIPTION SPECIFICATION PACKING LIST
Features:
- Static-free design (ESD safe),Knob type controls with LED status indicator.
- Easy grip soldering iron handle suitable for long hours of usage.
- 24V output to ensure safety of user and protect soldered components.
- AOYUE INT 936A uses PTC heating element that ensures faster heat up suitable for more demanding soldering jobs requiring higher heating power.
| SPECIFICATIONS | |
| POWER INPUT： | available in 110V / 220V |
| WEIGHT： | 2.5 Kg |
| MAIN STATION DIMENSION： | 115 x 155 x 90 mm |
| SOLDERING IRON | |
| POWER CONSUMPTION： | 60W |
| OUTPUT VOLTAGE： | 24V |
| TEMPERATURE RANGE： | 200°C- 480°C |
| HEATING ELEMENT： | PTC Heating ELement |
| TIP TO GROUND RESISTANCE： | Below 2 Ω |
| TIP TO GROUND POTENTIAL： | Below 2mV |
| AOYUE Int 936A Package Content | |
| 1 unit | Int936A Main Station |
| 1 PC | B002 Soldering Iron |
| 1 PC | 2660 Soldering Iron Stand |
| 1 PC | Power Cord |
| 1 PC | Instruction Manual |
